Asus RS300-E9-RS4 90SV03BA-M39CE0

Opis proizvoda

Specifikacije

    Procesor / Magistrala
    1 x Socket LGA1151
    Intel®Xeon®processor E3-1200 v6 product family
    Intel® Xeon® processor E3-1200 v5 product family
    Intel® Core™ i3 processors
    Intel® Pentium™ processors
    Intel® Celeron™ processors
    *Refer to support page for more information
    Generacija
    E9
    Čipset
    Intel® C232 Chipset
    Memorija
    Total Slots : 4 (2-channel)
    Capacity : Maximum up to 64GB UDIMM
    Memory Type :
    DDR4 2400 /2133 UDIMM non ECC and with ECC
    Memory Size :
    16GB, 8GB, 4GB UDIMM
    * Refer to support page for more information
    Slotovi za proširenja
    Total PCI/PCI-X/PCI-E/PIKE Slots: 2
    1 x PCI-E x16 (x8 Gen3 Link)
    1 x PCI-E x8 (x8 Gen3 Link)
    Skladištenje podataka
    SATA Controller :
    Intel® C232
    6 x SATA3 6Gb/s ports *1
    2 x M.2 connector (2280/2260/2242) *2
    Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows)
    (Support Software RAID 0, 1, 5, 10 )
    SAS Controller :
    ASUS PIKE II 3008-8i 8-port SAS 12G RAID card(Optional)
    ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card(Optional)
    Ležišta za diskove
    4 x 3.5” Hot-Swap HDD Bays
    2 x SSD Internal SSD Bays
    2 x M.2 (NGFF 2280/2260/2242)
    Dodatni skladištenje (FDD/CD/DVD)
    1 x Slim-type Optical Drive Bay
    Options: No Device / DVD-RW / DVD ROM
    Umrežavanje
    4 x Intel® I210AT + 1 x Mgmt LAN
    Grafika
    Aspeed AST2400 with 32MB VRAM
    Front Panel I/O Port
    2 x USB 3.0 ports
    1 x VGA port
    Pozadinski I/O Portovi
    4 x RJ-45 ports
    2 x USB 3.0 ports
    2 x USB 2.0 ports
    1 x VGA port
    1 x PS/2 KB/MS port
    1 x RJ-45 ports (One for ASMB8-iKVM)(Optional)
    Switch/LED
    Rear Switch/LED:
    1 x Q-Code/Port 80 LED
    1 x Power switch

    Front Switch/LED:
    1 x Power switch/LED
    1 x Location switch/LED
    1 x Reset switch
    1 x HDD Access LED
    1 x Message LED
    LAN 1-4 LED
    Upravljanje
    ASUS Control Center Enterprise (Optional)
    Optional ASMB8-iKVM for KVM-over-IP
    Usklađenost sa propisima
    BSMI, CE, RCM, FCC(Class A)
    Dimenzije
    615mm x 444mm x 44mm (1U)
    24.21" x 17.48" x 1.73"
    Format
    1U
    Težina
    Net Weight: 10.64 Kg
    Gross Weight: 16.76 Kg
    Napajanje
    1+1 Redundant 450W 80 PLUS Gold Power Supply
    Rating: 100-127Vac/200-240Vac,8A/4A ,47-63Hz, Class 1
    Uslovi okoline
    Operating temperature: 10°C ~ 35°C
    Non operating temperature: -40°C ~ 70°C
    Non operating humidity: 20% ~ 90% ( Non condensing)
    Napomena
    *1 4 by miniSAS HD + 2 x SATA
    *2 PCIE or SATA signal, gray SATA port will disable when M.2 is occupied
