Asus tuf gaming B550M-PLUS matična ploča

Opis proizvoda

Tip procesora: AMD
Podnožje: AMD® AM4
Čipset: AMD® B550
Format ploče: Micro ATX
Podržana memorija: DDR4
Bluetooth: Ne
Podržani procesori: - Treća generacija AMD Ryzen procesora
Memorija: 3rd Gen AMD Ryzen procesori
- 4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
Next Generation AMD Ryzen PRO Processors
- 4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
- Dual Channel Memory arhitektura
- ECC Memory (ECC mode) podrška varira od verzije CPU-a
Multi-GPU podrška: - AMD 2-Way CrossFireX tehnologija
Integrisana grafička karta: - 1 x DisplayPort 1.2
- 1 x HDMI 2.1(4K@60HZ)
Slotovi za proširenje: 3rd Gen AMD Ryzen Processors
- 1 x PCIe 4.0 x16 (x16 mode)
AMD B550 Chipset
- 1 x PCIe 3.0 x16 (x4 mode)
- 1 x PCIe 3.0 x1
Skladište: Ukupna podrška za 2 x M.2 slota i 4 x SATA 6Gb/s porta
3rd Gen AMD Ryzen procesori:
- 1 x M.2 Socket 3, sa M Key, Type 2242/2260/2280 (PCIE 4.0 x4 i SATA modes) storage devices podrškom
AMD B550 Chipset:
- 1 x M.2 soket 3, sa M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 i SATA modes) storage devices podrškom
- 4 x SATA 6Gb/s porta, podržava Raid 0, 1, 10
Mrežna karta: - Realtek RTL8125B 2.5Gb Ethernet
- TUF LANGuard
Zvučna karta: Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC
- Podržava: Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
Audio Feature:
- Exclusive DTS Custom for GAMING Headsets.
- Optical S/PDIF out port(s) at back panel
- Audio cover
- Audio Shielding
- Dedicated audio PCB layers
- Premium Japanese audio capacitors
USB: Rear USB Port ( Total 8 )
- 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C)
- 4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
- 2 x USB 2.0 port(s)(2 x Type-A)
Front USB Port ( Total 6 )
- 2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
- 4 x USB 2.0 port(s)(4 x Type-A)
Konektori na zadnjoj strani: - 1 x PS/2 keyboard/mouse combo port(s)
- 1 x DisplayPort
- 1 x HDMI
- 1 x LAN (2.5G) port(s)
- 2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C)
- 4 x USB 3.2 Gen 1 (blue) Type-A
- 2 x USB 2.0
- 1 x Optical S/PDIF out
- 5 x Audio jack(s)
- 1 x BIOS FlashBack Button(s)
Interni konektori: - 1 x CPU Fan connector(s)
- 1 x CPU OPT Fan connector(s)
- 2 x Chassis Fan connector(s)
- 2 x Aura RGB Strip Headers
- 1 x Addressable Gen 2 header(s)
- 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
- 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 4.0 x 4 mode)
- 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
- 1 x SPI TPM header
- 4 x SATA 6Gb/s connector(s)
- 1 x 24-pin EATX Power connector(s)
- 1 x 8-pin EATX 12V Power connectors
- 1 x Front panel audio connector(s) (AAFP)
- 1 x Clear CMOS jumper(s)
- 1 x System panel connector
- 1 x COM port header
- 1 x Speaker connector
BIOS: - 256 Mb Flash ROM, UEFI AMI BIOS
Ostalo: ASUS TUF PROTECTION
- ASUS DIGI+ VRM (Digital power design with Dr. MOS)
- ASUS Enhanced DRAM Overcurrent Protection
- ASUS ESD Guards
- TUF LANGuard
- ASUS Overvoltage Protection
- ASUS SafeSlot
- ASUS Stainless-Steel Back I/O
ASUS Q-Design
- ASUS Q-DIMM
- ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- ASUS Q-Slot
ASUS Thermal Solution
- Aluminum M.2 heatsink
ASUS EZ DIY
- BIOS FlashBack button
- BIOS FlashBack LED
- Procool
AURA Sync
- Standard RGB headers
- Addressable Gen 2 RGB header
